Input
• 1 pair XLR input (XLR 1)
• 4 pair line input via RCA
• (CD / MM / TUNER / AUX1 )

Output
• 1 pair XLR BLANCED output
• 1 pair RCA Single-ended output
• 1 pair RCA direct / Tape output

THD+N
• Balanced Output:

Input impedance / Vrms
• 47Kohm XLR / 4 Vrms max
• 22Kohm RCA/ 2.8 Vrms max
Setting input GAIN

• 0 db / +10 db / +20 db
• - 10 db / -20 db / -26 db

Voltage Output
• XLR : max 10 Vrms
• RCA : max 5 Vrms

Signal to noise ratio
• >110 db “A” weighted

Frequency response
• 5 Hz to 120 Khz +/- 0.5db

Dimension 420 * 330 * 85 mm - Weight 10 Kg
