Analog Input : XLR , CD , Tuner , AUX , PHONO MM

Digital INPUT : Asincron USB 2.0 , COAX , OPTICAL

Output :1 pair XLR BLANCED output /1 pair RCA Single-ended output /1 pair RCA direct / Tape output

Phones out : 5 mW. - 16 /32 ohm

THD+N :Balanced Output:

Input impedance / Vrms
• 47Kohm XLR / 4 Vrms max
• 22Kohm RCA/ 2.8 Vrms max

D/A section :
USB pcm 768Khz/ 32bit , DSD 512 – COAX 192Khz/24bit OPTICAL 96Khz/24bit

Voltage Output
• XLR : max 10 Vrms
• RCA : max 5 Vrms

Signal to noise ratio
• >110 db “A” weighted

Frequency response
• 5 Hz to 120 Khz +/- 0.5db

Dimension 420 * 330 * 95 mm - Weight 10 Kg
